Automatic Aseptic Sealer

LePurseal™ Automatic Aseptic Sealer II can be used for aseptic heat sealing of thermoplastic tubes (TPE material) and thermo plastic pump tubes (such as PharMed™ BPT, PureWeldXL) to meet the aseptic disconnection of thermoplastic tubes and maintain the sterility of products in non-sterile environments.

Effective maintenance of closed systems . The LePurseal™ Automatic Aseptic Sealer II has an optimized operating system based on Generation I to help operators improve development convenience and production compliance.

Request A Quote

Description

Feature

  • High flexibility and strong adaptability: Suitable for tubing with outer diameters of 1/4 inch to 1 inch (0.25 to 1 inch) , supports sealing for dry, wet, or liquid-carrying tubing
  • Readily available: Pre-set for various common brand tubing, ready for immediate use
  • Large built-in memory: Comes with 32GB of memory, meeting normal customer usage needs
  • Supports audit tracking and one-click login: One-click or account login options Unique account identification for easy tracking and investigation
  • Pre-positioning function: Reserved tubing width to reduce the risk of incorrect tubing placement
  • Portable: Lightweight equipment for easy transportation

Application

The LePurseal aseptic sealing machine II finds widespread use in aseptic disconnection within bioprocesses such as antibodies, vaccines, cell and gene therapies, and more.

SPECIFICATION

SPECIFICATION

ItemParameter
Input Voltage100~240 VAC， 50/60Hz
Power120 W
Pipe diameterOD 1/4”~ 1”（0.25~1 inch）
Pipe materialTPE thermoplastic tube or thermoplastic pump tube
Pipeline statusSupport dry pipe, wet pipe and liquid pipe
TimeWall thickness ≤ 0.188 inches, time ≤ 4 minutes
Use environment0.188 inches < wall thickness ≤ 0.25 inches, time ≤ 5 minutes 30 seconds
Limits of authorityIndoor use，Temperature：18 ~ 26 ℃
DimensionThree-level permissions or one-click login
Weight375*160*155 mm
Noise5.5 kg
Shell≤ 65 dB
Validation fileABS+PMMA+SUS304
IOQ Report

Ordering Information

Ordering Information

ItemCat.No.Packaging
LePurseal™ Automatic Aseptic Sealer IIBDASZ0001 pcs
IOQ authentication serviceKDB0101 set/time
New softwareKDB0111 time (≤ 3 specifications)
Maintenance serviceKDB0121 set/time
